4812016237 Main frame
4812028721 Side arm guiding
4812231639 Splash guard
4812036083 Steering guide
4812232118 Extension
4812027553A Gr.06 Side screed arms, hydr. locked
4812029165 Side screed arm, l.h.
4812232214 Side arm guiding
4720000097 Side arm guiding
4812029197 Side screed arm, r.h.
4812029191 Locking, hydraulic
4812027609 Hydraulic
4812033247 Control block
4812027436A Gr.03 Push roller, hydraulic
4812046568 Pillow block
4812027608 Hydraulic, push roller
4812044911A Gr.03 Push roller, hydraulic crosshead
4812004491C Covering, isolated
4812225668 Bulk head
4812225657 Air guide, rear
4812225681 Support plate
4812225682 Retainer
4812225689 Cover
4812233556 Covering center part, r.h.
4812009008 Isolation
4812226380 Retainer, l.h.
4812226135 Retainer, r.h.
4812226900 Hood support
4812225685 Hood support
4812226906 Intermediate section
4812225631 Intermediate section
4812226899 Air guide, r.h.
4812034771 Air guide, r.h.
4812226902 Air guide, l.h.
4812225640 Air guide, l.h.
4812225708 Door, l.h.
4812226336 Door, l.h.
Support rod
4812225725 Door, r. h.
4812226905 Iso- hood, r.h.
4812225715 hood, r.h.
4812226907 Iso- hood, l.h.
4812225717 hood, l.h.
4812226901 Covering center part, l.h.
4812225667 Covering center part, l.h.
4812226463 Disc frame
4812044596 Disc frame
4812229083 Hopper with dump plate
4812229108 Hopper, l.h.
4812231436 Locking
4812028563 Bulk material flap
4812229107 Hopper, r.h.
4812226069 Hopper, front hopper flap
4812226054 Hopper, l.h.
4812226029 Front hopper, middle
4812226004 Front hopper, l.h.
4812226060 Hopper, r.h.
4812226018 Front hopper, r.h.
4812027602 Hydraulic, front flap
